Three

Another thing that helps recording projects is if the sound board has a number of spare Aux or FX (Effects) Sends.  Some boards offer 6-8 sends for various reinforcement and recording needs.  If you have multiple tracks to record the live performance, use Direct-Outs when available for each active channel on the board.  Record as many separate tracks as you can for the most options during mix down.  If no Direct-Outs available use those Sends!  You can still record the Left and Right Main outs, then use Sends (you can use the ones not needed for monitors and effects…..) to record instruments you want to have independent mixing control later.  If the board offers Sub Groups – even better.  You can let the sound guru use Left and Right Main outs if they wish, and you use the Sub Groups to create 2 stereo mixes you can record as pairs.  Mix the drums and rhythm section (drums, rhythm guitar and bass guitar for the most part) with a stereo image by L-R panning of appropriate channels and assigning those channels to Sub Group 1.   Then take lead guitars and other instruments and hard-pan to the Left out of Sub Group 2, and the vocals hard-panned to the Right out of Sub Group 2.   In only four tracks you have great bed tracks to mix with, and control over vocal processing and adjusting volume of solo or lead instruments.  This still keeps that ‘live sound’ but helps create a better stereo environment and some independence when mixing and processing limited tracks.

One last set-up where I liked the results I got by using stereo in a different way with the following technique.  Instead of thinking left and right as the stereo image, I set up Audience position is 1 (left), and Stage position is 2 (right).  To achieve this I create a Mono mix from the sound board as described and available as above and record to channel 1 of the stereo recorder.  Then I take a quality microphone and hang it from the ceiling above the center of the stage and record this on channel two…….

I dump the ‘stereo’ wave forms into my computer and you can see right away they are offset a bit: one source delayed more than the other.  Recording software allows you to separate the stereo tracks and shift the start time just a little to match the other track and all of a sudden you have a new Live Stereo environment where you can hear what it sounds like to be ON STAGE, mixed with what it sounds like IN THE AUDIENCE.  Try it a few times and you can get great results if you are willing to sacrifice typical stereo images!



It never ceases to amaze me how inspired and creative I feel when I change the strings on my guitar(s).  Simple chords sound gorgeous.  The whole body of the guitar resonates with depth.  This makes experimenting and exploring new areas delightful.  It is important to keep tools of the trade not just working properly but living up to their potential.

I watch vocalists go into the recording booth and put on really nice headphones to get a direct audio feed from the soundboard.  Maybe this is not their first time, but when they start singing – and can truly hear what their voice sounds like they get this big grin that turns into a surprised smile.  Hearing through the studio system vocalists can make nuanced changes as they sing ……. and hear the difference.  This gives them more control and immediate results.  They become confident enough to experiment and innovate.  I hope it feels similar to playing my 12 string guitar with brand new strings.

Pictured are of some of my guitars, the drummer from Euphoria/The Chase – Mike Gill, and Steve Steinmann of Iridium.

What tools do you use that benefit from regular care?

This slideshow requires JavaScript.

Unseen Dimensions

It is great to be human.  We see beyond our primitive instincts.  We learn by watching others.  We know things our senses blind us to.  We carry lessons learned from one event and apply to others.  This is one of the reasons I love photography.  Our naked eyes and untrained mind can hide what is right in front of us.  With the simple ability to focus and zoom, we are no longer limited to what the unaided eyes communicate to the brain.  With the pictures in this post, it is easy understand the dramatic change in focus alone.  Each picture was taken in the same place and at almost the exact same time.  A slight change in focus and what was invisible becomes clear.  Zoom in further and what is hidden directly in front of us becomes unmistakable.

Perhaps looking for other dimensions is just like that; maybe we need a simple device like the lens array in a camera.  Once we learn how to look – we may be able to see them all around us.

I guess I never really came up with a name for this tune.  Sometimes I will write lyrics and give it a working title.  I do the same thing with musical pieces I am working on before there are dedicated lyrics assigned to the tune.  As I continue to work on a piece, the name often changes when chords are matched with a set of lyrics.  On rare occasion it happens at the same time, and that process is a little different – and easier!  This is one of those weird situations where I never got to either, and this has always been referred to by the date…..  March of 1990.

March in this case also has a double meaning.  It is the pull away from the Winter season where I live.  The steady movement of new life.  The pace of growth that cannot be stopped. The instrumental tries to match that drive and frantic pace of the season.   Driving rhythms, collage of melodies, bouncing themes – and then to dynamics and a reflection of what is now past.  Then back to driving growth.  That is what I think about as I listen to this tune.  Even now, heading to Winter, I feel that March pushing forward.

Back to the Atari 1040 ST, I am sequencing all parts for this tune.  I believe I added a new tone module from EMU called the Proteus 1.  This was an amazing machine and I have not found anything as good and simple to use as the Proteus series.  It was really cool for two major reasons in my opinion.  1) the sounds were just awesome for the time and there were lots of sounds on board.  2) the operating software used was just made for MIDI geeks like me.  It was very simple and allowed the Proteus 1 to create splits, layers and zones, but it easily allowed you to access all 16 MIDI channels at the same time.  I could write a few articles on this alone, but for now it meant you could assign a different sound to any or all of the 16 channels independently.  As described in the MIDI series, this was great because you could use channel 1 for piano, channel 2 for organ sounds, channel 3 for strings, channel 4 for brass or orchestra sounds, 5 for flutes, 6 for sound effects, 7 for guitar sounds, 8 for solo instruments, 9 for the bass guitar sound, 10 for the standard drum channel and still have channels left over.  Playing out in bands and in the studio with this was just a dream.

https://itunes.apple.com/us/album/touch-down/id962542289

“Rainy Day”

Cruisin’ down the avenue

Raining in the lightning.

Listening to the radio

Cruisin’ in the darkness.

           Peddle down, let’s burn this town

           Fire from my tires.

           Reflections in my rear view mirror,

           I will find tomorrow.

Comin’ down the avenue

Raining and the lightning.

Reflections in my rear view mirror

I will find tomorrow.

Go for ride real late at night

Rain comin’ down like it usually does.

So I turn the radio to the right

Playin’ the same songs as the other night.

So I slammed the door and I left for good

Now you find me driving in your neighborhood.

Don’t explain it to me, it’s well understood

Everything you do for me is for my own good.

           Turn ‘round the corner I’m still losing my mind

           So I punched it down and left it all behind.

           Tryin’ not to cry I push it all back

           Racing fast to nowhere on a one way track.

           No colors at all, just the burning headlights

           And the crackling of lightning tearing into the night.

           People ask me what I do at night

           I tell them only one thing makes me feel all right.

           It makes me feel all right.

Lyrics by Michael & Ellen Kennedy

Music by Michael Kennedy

(c) 1986

Live_Stage_New2

Think of the stage as a speaker sitting in front of the audience….. sometimes the club or venue actually looks like a box where the performers are positioned. You have the low-end Bass Guitar, Kick Drum and Floor Tom and maybe keyboard sounds or textures. You have the Guitar and Vocals in a mid-rangy area and at the upper end you have symbols and higher range Guitar and Keyboard sounds. All inside the same box just a blasting away at different levels and pointed in all directions.

Now you have a better understanding of the challenge of making these various chunks into a tasty audio stew!

For the best way to present music to the savvy listeners of today, we do what has been done for decades. In the stereo image, you want to create a “room” or “place” for the listener. We have become comfortable with the very low end sounds coming from both speakers at about the same volume. This places the sound to the center of the listener’s field.

We like the vocals or in most cases the melody line to be in both sides equally, again placing the singer in the middle of the left-right field. We are fine if other instruments or singers are more to the left or right as long as the main sounds are where we expect them. We usually place big speakers on either side of the stage facing the audience…… usually in front of the stage and performers…. But as mentioned above this is not a finely tuned speaker cabinet by any means. The components are not necessarily proportionally balanced in volume or location. Setting up the Stage and PA system with this in mind can help reinforce the natural stereo image out in the audience.

Now that I have made a connection that is awkward if not confusing, even though the PA system in all likely hood is a Mono mix coming from both sides or columns of speakers, the listener still hears this as a stereo field. They want the low-end sounds or tones from the center of the stage. Typically the drum – the Kick Drum to be specific for this example – is the most used and most amplified instrument in band situations or where you have audio media. The Bass Guitar player is usually next to the drummer. This helps them keep tighter timing and solid beat, but also supports the stereo image of the listener.

Guitar and other amplified instruments on stage can be heard more from their side of the stage than from the other as an easy example, even if the volume through each side of the Main is sent the same level signal. If keyboards are on the opposite side of the stage from the guitar and also uses a monitor or amp, standing closer to them in front row can make it seem like the keyboards are too loud and those on the other side of the stage think the guitars are somewhat overbearing. It won’t stop them from standing there though! As you get further away from the front of the stage or if the venue is very large, this stereo effect has less and less meaning to the listener. Still, as a rule, most sound systems do not place low-end PA cabinets (or dumps) on one side of the stage and the mid or hi-end cabinets on the other side. It can be however, advantageous to place the low-end dumps in the center of the stage or along the front-center stage area. To make this more inclusive, it is also more comfortable to hear low-end tones coming from an elevation point lower (on the floor, for example) and the higher tones or frequencies coming from higher points (mounted above the stage or on tall poles).

If the volume on stage becomes to strong a level it will negatively affect all the above and more. To reinforce another post of mine, musicians just need to worry about performing great – we sound geeks will make them sound good and loud! I keep dreaming.

I spent a lot of time in smaller clubs with crowded stages and audience sizes varying from handfuls to standing room only capacity. The challenges come from each of them and have different resolutions. In some ways, I think the large clubs and outdoor events are the easiest to set up and run sound for. If it is a big stage or large arena, you turn everything up so it is in the main mix or no one will hear it. The smaller clubs you don’t necessarily put a microphone on every instrument. You cannot out-power a guitar player with a stack of cabinets. You might not be able to set up independent or multiple Monitor Mixes (stage mix for performers) and many times you have to share monitors (the cabinets or speakers themselves in this case…) between performers with various needs. Add keyboard player(s) or a horn section and it quickly over burdens the PA or sound system.

Setting up the stage with a few solutions in mind can help in each of these situations. In smaller clubs you might not have many options for the arrangement of musicians on stage. Some restraints may be obvious at first. Some will catch you off guard. Knowing what you are up against though can trigger steps to prevent problems.

These are basic but can avoid a lot of small-headache issues:

Place snake closest to center of stage if that is closest to where instruments/vocalists are positioned. Shorter cables are better if they allow performers needed mobility.

Make sure you know where the AC power outlets are. It is a drag to set everything up and not be able to plug in your power amps. (I also recommend bringing long heavy-duty extension cords for versatility)

Try to plug all stage instruments and PA gear along with the mixing board and external sound gear to the same AC breaker box.

Try to plug all lighting or other powered systems to a separate AC breaker box. (If it does not connect to the mixing board to make noise; plug it into another breaker box)

Use balanced (three wire cables) whenever possible. (I have been caught by 1/4″ audio jacks without locks getting knocked out in the middle of a gig more than once and hate anything that does not lock into position. rant now over)

Keep stage volume as low as possible (this is a couple posts all by itself!)

Consider cross-firing stage instrument amps like guitars and bass – rather than pointing at audience.

Make sure sound board is in the best sounding location and also close enough to the stage to connect snake and all gear – especially if you have to route the snake around the outside of the event area for safety or other reasons.

Cables are the first thing to go wrong even when properly handled and maintained. Bring a lot of SPARES.

Turn all power amps (including ones that are built into the speakers OFF or all the way DOWN when connecting or disconnecting gear. (there are shortcuts and general exception practices we will detail later).

Turn all recording gear OFF or down all the way until all devices and channels are connected and tested.

Make sure speaker cables (Mains and Monitors) are long enough to reach the power amps. I bring two long length sets of speaker cables and two short length sets (no matter how many total speakers I have, I will have two full sets….). If one side of the stage is where the power amps are, I use the short cable and the other one might require the longer cable. Sometimes you need both long cables. If I need a spare, I have two!

Drum risers could need low end cuts and even gates to reduce unwanted tones and resonances.

Color Code anything you can. Cables, Mic stands, Monitors, In-Put Channel labels or External gear/boxes. Make it easy to identify in low light. Green microphone goes with green cable goes to green snake plugs into green channel….. I also add a number to make larger sessions manageable. Vocal green 1, 2, 3…. Drum blue 1, 2, 3….. Brass white 1, 2, 3……

Not rocket science, just some thoughts. But if you get in the habit of considering these and other tips each time before you start hauling in equipment into a new venue, your set-ups will become quick and routine, even if the environment is new. If you keep all your gear in one place there are short cut power-up and power-down sequences I will detail soon.

For this project, we needed a few volunteers and some inexpensive themes.  We took advantage of the resources available.  Ric worked as an auto mechanic so we started there.  I made a couple cameo appearances but the story is about working hard and no time for creating and performing  (you have heard this theme before !) During the Jeep ride up the hill you do not see the driver (Gorgeous George…) but he is still in the Jeep as Ric appears to be pulling it (and metaphorically his career) up the hill.  George is pulling in and out on the clutch so there is real tension and sometimes Ric is literally being pulled back by the Jeep.  Who needs acting skills!

When we moved to the live Personal Touch segments it is the duo before Phyllis Ann officially joined us.  You can see Ric is kicking bass pedals and controlling an accompaniment system.  On his guitar you can see him tap two silver round pads. The one triggers a drum crash from the accompaniment system he is controlling. The other pad triggers a drum pattern change to a drum roll for as many times as he taps the pad.  He is the lead vocalist for the song and yes, he is also playing guitar…….. I am playing my Arp Odyssey, a Yamaha electric piano and my Yamaha DX7 and doing back-up vocals in this video.

For this I think we went into the club the day of our regular performance and shot the raw video segments for the Walking Man video.  We played other tunes for other projects but there is no real audience and we only had to set up once to do the video shots and perform later that night.  I try to be within budget (usually none….) and also with no wasted effort!

For a duo, we packed a lot of punch.  Not only because it was just two of us in the beginning, but  also in the space we could fit.  We had no live drummer or bass player.  I could play guitar and sing and when I was not playing guitar (and indeed, in some songs I would play guitar and keyboards) I could play keyboards and/or control the drum machine that I programmed.

Ric sang and played the guitar and almost all lead guitar parts as he also controlled the accompaniment system that had preset drum patterns, bass pedals, and a foot pedal and switches that let him add backing instruments like strings or piano sounds and at the same time determine if the backing instrument chords were played Major, Minor, 7th etc.  We fit anywhere, as long as they had tall ceilings LOL!!!

Believe it or not, MTV started off as a media outlet for – VIDEOS!  It was not what it is today.  Music videos were still relatively new and there were not that many out there but they started being produced in numbers once MTV provided an outlet for them. The Chicken or the Egg thing all over again.  I did not own any video equipment, but I was familiar with photography and music, so it was a natural interest for me.  Back then, cable companies were starting to set up monopolies in various cities throughout the US and we were in the Warner Amex territory.  As part of their agreement with the city to provide cable and other services, Warner Amex made some of their equipment and channels available to local citizens. They provided training and allowed non-profit citizens to go through camera and editing training and once completed you could schedule use of their equipment to create content for viewing on their Public Access channels.

I was one of the first (my card was # 000090!!) to sign up for the training classes.  I would borrow their equipment and film bands and live performances, family growing, along with a number of other projects.

My first project was to make a video that introduced the idea and benefits of the Public Access program, (we hoped if we had a complimentary message it would be good for PR and relationships with the people that administered the program, (we were right). and a music video idea we had been working on.  This is by definition low-budget and is dated by equipment and resources available today. But it was a learning experiment and was a lot of fun.  To do a lot of what we did it took a bunch of planning and trial and error.  I had been playing keyboards for a very short time and there are a bunch of mistakes, I was new with the video editing and production, but not this was not bad for the first release.  Usually, I am also the cameraman, but filming my own band required additional operators.  I edited the video from the collection of raw tapes and a live performance of the song.

This video features my younger brother as the narrator and the music is from the duo I was in at the time called, “The Personal Touch.”  The intro theme is a musical piece called “The Big D Jam”.  The video is based on a song the guitar player wrote called “Transaxle“.   We took vague ideas and filmed them all.  Then edited them into something semi-cohesive!  There are a bunch of funny stories that went into the making of Walking Man but I will spare you for now.  The end credits use a song of mine introduced earlier called “The Pleasure Tax“.

As with many of these blasts from the past, there are lots of good memories and a number of painful ones.  Looking at this video again so many years after, I see my youngest brother Chris in his healthy days doing the narrative part introducing the musical video before health problems including throat cancer took their toll.  This is when we thought we would last forever….. there was no end in sight.  We do not last for ever.  For him, the end was so close to the beginning.   We all have our vices, but with legal ones like tobacco and alcohol killing people every day, we all know someone that has been affected by the results. Here is the real message we should be sending; These drugs may not kill you.  You will not lose ten years of your life.  You will survive – and grow old – and suffer – for decades, with a disease that is eating you from the inside out. I am glad I was there to help him a little as he faced the end.  I would have given anything to find another path for him, but he knew where he was going.  It did not stop him and neither could I.

Most of the connectors used for outputs will be 1/4″ male jacks.  These can be for ‘grounded’ (three-wire) or two-wire cables.  To make this part confusing, the cables can be made or changed with adapters to almost any connector type.  For long distances we prefer grounded or three conductor-wire cables as the third wire is used to take common signals from the other two wires, and ‘dump them to ground’.  Common signals would be interference and noise as the plus and negative wires are carrying the signal from the board.  The result is good signal with low noise introduced.  Guitar and keyboard cables typically go shorter distances and typically have a higher or stronger output signal than a microphone for example.  The cables in the snake will use three wire grounded shielded cables even if they are 1/4″ male connectors.

So we might expect to have an XLR connector for the Main Outs to the Main House power amps, but this is not a guarantee.  If 1/4″ jacks are provided it is recommended to use grounded three wire cables.

Most cables will provide a male connector on one end and a similar but female connector on the other end.  Male connectors are often used to connect to In-Puts and Female connectors are often used to connect to the Out-Put.  The male connector of the microphone cable connects to the mixing board In-Put and on the other end the female connector will connect to the microphone out.  Generally speaking there is little advantage plugging an in to an in or an out to another out.   I like to state the obvious LOL!

The mixing board will give us a Main Left and Right out, and probably a Mono Main Out.  These will be connected to the Main or House power amps.  During an event, the amps are usually turned all the way up and the House volume is ultimately controlled by the Main L-R faders on the mixing board.  This is why it is important to turn the Master Volume Faders on the mixing board all the way down whenever connecting or disconnecting equipment or making dramatic changes.

Depending on the board size and configuration you may also have a 1/4″ Direct-Out for many if not all input channels. (this is REALLY cool for recording and a lot of other creative uses…)   These can be really handy for independent channel recording, triggers, audio effects and alternate mixes to name a few.  Basically connect these to external recorder, processor or triggering gear as needed.  I will give some examples as the series expands to other main topics.  You will also have a number of Sends that are used for a variety of tasks and have different names, but with a few configuration details are for the most part the same thing.  Effect Sends, Monitor Sends, Auxiliary Sends, Sub Sends are splitters; they split the signal – keeping the one going to the House or recorder – and allowing you to send a lot or a little of that signal to the Send of your choice using the Send knob. As in the Monitor amps and House amps, the volume knob will ultimately be used to send the proper signal level to the external (and internal) devices or effects.  If you ‘send’ this to a digital delay, it may also have its own input and out put level knobs.

You may also have a two-track input and/or out put.  This is for playing stereo audio devices and for a straight stereo record out option.  Handy to listen to practice tapes, intermission music, PA system tests and other performance related media.
