Another thing that helps recording projects is if the sound board has a number of spare Aux or FX (Effects) Sends.  Some boards offer 6-8 sends for various reinforcement and recording needs.  If you have multiple tracks to record the live performance, use Direct-Outs when available for each active channel on the board.  Record as many separate tracks as you can for the most options during mix down.  If no Direct-Outs available use those Sends!  You can still record the Left and Right Main outs, then use Sends (you can use the ones not needed for monitors and effects…..) to record instruments you want to have independent mixing control later.  If the board offers Sub Groups – even better.  You can let the sound guru use Left and Right Main outs if they wish, and you use the Sub Groups to create 2 stereo mixes you can record as pairs.  Mix the drums and rhythm section (drums, rhythm guitar and bass guitar for the most part) with a stereo image by L-R panning of appropriate channels and assigning those channels to Sub Group 1.   Then take lead guitars and other instruments and hard-pan to the Left out of Sub Group 2, and the vocals hard-panned to the Right out of Sub Group 2.   In only four tracks you have great bed tracks to mix with, and control over vocal processing and adjusting volume of solo or lead instruments.  This still keeps that ‘live sound’ but helps create a better stereo environment and some independence when mixing and processing limited tracks.

One last set-up where I liked the results I got by using stereo in a different way with the following technique.  Instead of thinking left and right as the stereo image, I set up Audience position is 1 (left), and Stage position is 2 (right).  To achieve this I create a Mono mix from the sound board as described and available as above and record to channel 1 of the stereo recorder.  Then I take a quality microphone and hang it from the ceiling above the center of the stage and record this on channel two…….

I dump the ‘stereo’ wave forms into my computer and you can see right away they are offset a bit: one source delayed more than the other.  Recording software allows you to separate the stereo tracks and shift the start time just a little to match the other track and all of a sudden you have a new Live Stereo environment where you can hear what it sounds like to be ON STAGE, mixed with what it sounds like IN THE AUDIENCE.  Try it a few times and you can get great results if you are willing to sacrifice typical stereo images!







In most situations when you want to record a performance, you might not have a lot of time to set up.  The environment might not be perfect, and there are other needs than getting a great recording.   I have tried and been quite successful with a number of techniques.  I will offer a few here for your consideration.

Getting a good mix from the sound board Mono Out or Main Left and Right Outs in a small or medium size venue is very easy to set up, but most likely to be disappointing. The needs of the audience in a live situation can be the exact opposite from the recording engineer’s.  As mentioned in the beginning of this series, LSR is reinforcement.  The sound person will amplify the weaker signals in the House or Mains; vocals – along with a LOT of effects, acoustic guitars, flutes, and even the drums.  They might not need to reinforce the lead or bass guitar as much. So the board mix is heavier on vocals, effects, and keyboard in some cases.  Not a great listen for most people.                                                                                                                                       You can set up a sub-mix if the sound guru gives you access.  If they run Left (Mono) like most venues, you can create your own mix using the Right Mono out.  Using the pan for each channel, keep full signal going to the Left out, and pan toward Center position to send desired amount of signal to the Right out.  You might want to isolate the guitar or bass, add a little toms if they are mike’d, but not heavy in the mix.  You can mix the two outs if you record in stereo and get a great live sound.  This will not give you a perfect stereo field, but most audiences do not remember concerts in stereo.  The sound seems to come from the stage, not left and right cabinets in front of the stage.

I have also had luck with those portable stereo digital recorders available now for what I think is really cheap for what they do.  You need to set them up correctly and take care of them but they are so easy to set up and you get great sound in various environments.  If you have a SAFE place where you will hear more of the band than the audience (sounds easier than it really is) this is worth a try.

While performing with my last cover band, Crash Landing, we played local clubs, festivals and private parties.  In this picture of a live set up, you will see a fairly standard rock/blues/country/alternative/jazz band stage arrangement;  drums center rear, Lead Vocalist center front.  Keys (and/or rhythm guitar) on the left as you look at the stage and the lead guitar player on the right.  In smaller clubs the keyboards get crunched back in the corner next to the drummer……  no sour grapes here!  Bass player close to the drummer. (either side doesn’t really matter)  In reality, most bands will not practice in this configuration, but this is the way most of us play out live and we are quite used to it.  In our case, Crash Landing has a number of vocalists.  All but the drummer sings in this band.  The bass player takes front stage position and sings a number of lead vocals.  So does the guitar player.  You can see where the microphone stands are placed for the vocalists.  Close up pictures later in this series will show other microphone positions for the instruments.  These are good places to start.  If you have limited time or setting up for a number of bands in an evening, you go with the standard format and shape the sound from the board as much as possible.  Knowing or having experience doing the quick set-up successfully a few times you will see the standard configuration and mic placements work well for the vast majority of performances.

We can also see the positioning of the vocal stage monitors across the front of the stage.  There are various thoughts on how to set these up but the differences can seem minor.  For this many vocalists across the front, this spacing and direction worked fairly well.  The drummer and/or other non-vocalists might also need monitors.  (it would not be unusual for the keyboard player requiring a monitor to hear the keyboards and a vocal mix if they sing)  This stage size gives players room to breath AND hear.  When inside on a smaller stage, everything seems to collide and jumble.  Outside you can hear yourself play much better (depending on the sound engineer, of course) and at times you might actually struggle just a little to hear the other players!  Take two steps closer to them and they are plenty loud.  This should be an easier situation for a sound engineer.  If I had to do a first gig in my life as a practice run, I would want to do an outdoors gig.

Crash Landing

If we start from the stage things actually be come easier.  If the mixing or sound board is the hub of processing sounds, the stage is the hub for generating sounds!  Most Live Sound Reinforcement events would benefit if the engineer spent more time here.  It is not uncommon for the sound guy to spend fifteen minutes making sure the kick drum has every frequency needed pumped up loud enough to message your spine (and ear drums) but they take two minutes to set up the stage monitors.  And most do that right after the band sets up  - – – – – when there is no music playing!

So let’s take a minute and walk up on stage and see what it physically looks like.  If you are familiar with the band you have a good idea of acceptable arrangements:  Overall dimensions.   Where are the riser(s).  How tall are the ceilings. Where are the AC outlets.  You may not be able to direct where the performers set up in a number of cases but you can influence some.  Where should the drums/keyboards/horn section go.  Where is a good central place for the snake (multi-connector cable connected to the mixing board).  Where do the monitors go (unless using in-ear monitor systems).  For me, this is also a good place to determine where the house speaker cabinets and amplifiers are placed.  BTW, if you are not familiar with the band or act make it a practice to find out.  Go to their website or media page. Get an idea of what they do live, if you can.  Ten minutes on-line will save you a bunch of headaches if they turn out to have specific requests for their instruments or performers.  I can also tell you from personal experience if you go up to Player C and say, “Hey, I got that adapter you need for your axe”, the player is going to notice the effort.  They will relax and you can let them know they are in good hands.  Getting the band’s cooperation is not necessary.  It is not in the books.  In some situations it might even be a waste of time.  I will still try every time.  Getting their cooperation…… sets up a great performance.  Then I focus on stage sound…..  and most band members will go out of their way to help during sound check and throughout the performance before 20 minutes of equalizing the kick drum.

Now that you have a good idea of the dimensions and set up requirements, place each performer in the best location and set up their respective microphones and monitors as needed.  Set up House gear and test.  From the mixing board, use a ‘talk-back’ microphone sent to the stage monitors to test and communicate with the performers.  Band members might feel like they are inside a cage at the zoo, looking out at the visitors!  Sometimes all you can see are the stage lights in your eyes.  The venue may be quite dark.  So the more comfortable they feel; the more like rehearsal you make it feel, the better the blend among performers.  The better the blend, the better the whole event will unfold.

Going forward I will go over a few details and outline this process to make it easier as well fun!

________________________________________________________________

Through the beginning to the end of the last chapter, we have concentrated on the hub or the central nervous system of a Live Sound Reinforcement assignment.  I have been focusing a bit on live performance in a typical band or musical event.  We now understand how most equipment for the House PA, the stage monitors, effects, and even lighting systems use the mixing board as the central hub.  The mixing board’s usefulness does not end there!  Once equipment is set up, connected, turned on and confirmed functional, most of the adjustments made for the rest of the evening will happen because of changes to the mixing board.  It also becomes the Master Device, and all other connected devices are ultimately controlled by the mixer.  The sound engineer is the ONLY person that should touch the mixing board.

The next logical step would be to describe the components of the House PA system and how much power (or how much money do I need to spend….).  After all, this is what most people hear, right?

Obviously, I set up as a trap question.  The answer seems obvious.

If I said, “I sound like a broken record”, most young readers will not know what that means! But I will repeat myself on certain themes and I feel one a’ comin’!  The next important thing is not the House PA and the number of speakers and amplifiers you need.  Most small venue mixing engineers go straight for the house and main systems, completely ignoring the most important ingredient guaranteeing a great performance.  We will avoid that trap now and focus on the stage and more importantly – the musicians on the stage.

When bands practice, they ultimately find a good use of space and volume so each member can achieve the two primary goals;

1) Hear myself (usually louder than any one else.  This is not ego and we will get into that later)

2) Hear the other performers (usually not as loud as the performer wants to hear him/her self!!)

Once they settle in and can accomplish the above – practice is comfortable and productive.  Each member can hear themselves and can also hear enough of the other members to blend with them.  If you saw a live symphony orchestra and all you could hear were the trombones, it would seem like an awful performance.  If you were a musician in the orchestra and all you could hear were the trombones……………

Now we can go back to the band members standing on a stage or venue they have never seen or played in……   and now understand that this is a very real challenge, and the smaller the venue… the smaller the budget.  Lack of Resources can be difficult challenge to overcome.

In larger venues it was quite normal to have a smaller mixing board off to the one side of the stage.  All the instruments and monitors would connect to this mixer, and it would ‘split’ all channels and send them equally to the House mixing board out in the audience area.  (it can also be used to send signals to a recording van parked outside).  The sound engineer on stage makes the band members happy by concentrating on the performers but does not affect the signal going to the House board.  That way the House Engineer has full control of the unaffected incoming channels from the stage board.

Good enough for now and in the next few sections I will focus on the stage sound and mix.

Live_Stage_New2

Think of the stage as a speaker sitting in front of the audience….. sometimes the club or venue actually looks like a box where the performers are positioned. You have the low-end Bass Guitar, Kick Drum and Floor Tom and maybe keyboard sounds or textures. You have the Guitar and Vocals in a mid-rangy area and at the upper end you have symbols and higher range Guitar and Keyboard sounds. All inside the same box just a blasting away at different levels and pointed in all directions.

Now you have a better understanding of the challenge of making these various chunks into a tasty audio stew!

For the best way to present music to the savvy listeners of today, we do what has been done for decades. In the stereo image, you want to create a “room” or “place” for the listener. We have become comfortable with the very low end sounds coming from both speakers at about the same volume. This places the sound to the center of the listener’s field.

We like the vocals or in most cases the melody line to be in both sides equally, again placing the singer in the middle of the left-right field. We are fine if other instruments or singers are more to the left or right as long as the main sounds are where we expect them. We usually place big speakers on either side of the stage facing the audience…… usually in front of the stage and performers…. But as mentioned above this is not a finely tuned speaker cabinet by any means. The components are not necessarily proportionally balanced in volume or location. Setting up the Stage and PA system with this in mind can help reinforce the natural stereo image out in the audience.

Now that I have made a connection that is awkward if not confusing, even though the PA system in all likely hood is a Mono mix coming from both sides or columns of speakers, the listener still hears this as a stereo field. They want the low-end sounds or tones from the center of the stage. Typically the drum – the Kick Drum to be specific for this example – is the most used and most amplified instrument in band situations or where you have audio media. The Bass Guitar player is usually next to the drummer. This helps them keep tighter timing and solid beat, but also supports the stereo image of the listener.

Guitar and other amplified instruments on stage can be heard more from their side of the stage than from the other as an easy example, even if the volume through each side of the Main is sent the same level signal. If keyboards are on the opposite side of the stage from the guitar and also uses a monitor or amp, standing closer to them in front row can make it seem like the keyboards are too loud and those on the other side of the stage think the guitars are somewhat overbearing. It won’t stop them from standing there though! As you get further away from the front of the stage or if the venue is very large, this stereo effect has less and less meaning to the listener. Still, as a rule, most sound systems do not place low-end PA cabinets (or dumps) on one side of the stage and the mid or hi-end cabinets on the other side. It can be however, advantageous to place the low-end dumps in the center of the stage or along the front-center stage area. To make this more inclusive, it is also more comfortable to hear low-end tones coming from an elevation point lower (on the floor, for example) and the higher tones or frequencies coming from higher points (mounted above the stage or on tall poles).

If the volume on stage becomes to strong a level it will negatively affect all the above and more. To reinforce another post of mine, musicians just need to worry about performing great – we sound geeks will make them sound good and loud! I keep dreaming.

I spent a lot of time in smaller clubs with crowded stages and audience sizes varying from handfuls to standing room only capacity. The challenges come from each of them and have different resolutions. In some ways, I think the large clubs and outdoor events are the easiest to set up and run sound for. If it is a big stage or large arena, you turn everything up so it is in the main mix or no one will hear it. The smaller clubs you don’t necessarily put a microphone on every instrument. You cannot out-power a guitar player with a stack of cabinets. You might not be able to set up independent or multiple Monitor Mixes (stage mix for performers) and many times you have to share monitors (the cabinets or speakers themselves in this case…) between performers with various needs. Add keyboard player(s) or a horn section and it quickly over burdens the PA or sound system.

Setting up the stage with a few solutions in mind can help in each of these situations. In smaller clubs you might not have many options for the arrangement of musicians on stage. Some restraints may be obvious at first. Some will catch you off guard. Knowing what you are up against though can trigger steps to prevent problems.

These are basic but can avoid a lot of small-headache issues:

Place snake closest to center of stage if that is closest to where instruments/vocalists are positioned. Shorter cables are better if they allow performers needed mobility.

Make sure you know where the AC power outlets are. It is a drag to set everything up and not be able to plug in your power amps. (I also recommend bringing long heavy-duty extension cords for versatility)

Try to plug all stage instruments and PA gear along with the mixing board and external sound gear to the same AC breaker box.

Try to plug all lighting or other powered systems to a separate AC breaker box. (If it does not connect to the mixing board to make noise; plug it into another breaker box)

Use balanced (three wire cables) whenever possible. (I have been caught by 1/4″ audio jacks without locks getting knocked out in the middle of a gig more than once and hate anything that does not lock into position. rant now over)

Keep stage volume as low as possible (this is a couple posts all by itself!)

Consider cross-firing stage instrument amps like guitars and bass – rather than pointing at audience.

Make sure sound board is in the best sounding location and also close enough to the stage to connect snake and all gear – especially if you have to route the snake around the outside of the event area for safety or other reasons.

Cables are the first thing to go wrong even when properly handled and maintained. Bring a lot of SPARES.

Turn all power amps (including ones that are built into the speakers OFF or all the way DOWN when connecting or disconnecting gear. (there are shortcuts and general exception practices we will detail later).

Turn all recording gear OFF or down all the way until all devices and channels are connected and tested.

Make sure speaker cables (Mains and Monitors) are long enough to reach the power amps. I bring two long length sets of speaker cables and two short length sets (no matter how many total speakers I have, I will have two full sets….). If one side of the stage is where the power amps are, I use the short cable and the other one might require the longer cable. Sometimes you need both long cables. If I need a spare, I have two!

Drum risers could need low end cuts and even gates to reduce unwanted tones and resonances.

Color Code anything you can. Cables, Mic stands, Monitors, In-Put Channel labels or External gear/boxes. Make it easy to identify in low light. Green microphone goes with green cable goes to green snake plugs into green channel….. I also add a number to make larger sessions manageable. Vocal green 1, 2, 3…. Drum blue 1, 2, 3….. Brass white 1, 2, 3……

Not rocket science, just some thoughts. But if you get in the habit of considering these and other tips each time before you start hauling in equipment into a new venue, your set-ups will become quick and routine, even if the environment is new. If you keep all your gear in one place there are short cut power-up and power-down sequences I will detail soon.

Most of the connectors used for outputs will be 1/4″ male jacks.  These can be for ‘grounded’ (three-wire) or two-wire cables.  To make this part confusing, the cables can be made or changed with adapters to almost any connector type.  For long distances we prefer grounded or three conductor-wire cables as the third wire is used to take common signals from the other two wires, and ‘dump them to ground’.  Common signals would be interference and noise as the plus and negative wires are carrying the signal from the board.  The result is good signal with low noise introduced.  Guitar and keyboard cables typically go shorter distances and typically have a higher or stronger output signal than a microphone for example.  The cables in the snake will use three wire grounded shielded cables even if they are 1/4″ male connectors.

So we might expect to have an XLR connector for the Main Outs to the Main House power amps, but this is not a guarantee.  If 1/4″ jacks are provided it is recommended to use grounded three wire cables.

Most cables will provide a male connector on one end and a similar but female connector on the other end.  Male connectors are often used to connect to In-Puts and Female connectors are often used to connect to the Out-Put.  The male connector of the microphone cable connects to the mixing board In-Put and on the other end the female connector will connect to the microphone out.  Generally speaking there is little advantage plugging an in to an in or an out to another out.   I like to state the obvious LOL!

The mixing board will give us a Main Left and Right out, and probably a Mono Main Out.  These will be connected to the Main or House power amps.  During an event, the amps are usually turned all the way up and the House volume is ultimately controlled by the Main L-R faders on the mixing board.  This is why it is important to turn the Master Volume Faders on the mixing board all the way down whenever connecting or disconnecting equipment or making dramatic changes.

Depending on the board size and configuration you may also have a 1/4″ Direct-Out for many if not all input channels. (this is REALLY cool for recording and a lot of other creative uses…)   These can be really handy for independent channel recording, triggers, audio effects and alternate mixes to name a few.  Basically connect these to external recorder, processor or triggering gear as needed.  I will give some examples as the series expands to other main topics.  You will also have a number of Sends that are used for a variety of tasks and have different names, but with a few configuration details are for the most part the same thing.  Effect Sends, Monitor Sends, Auxiliary Sends, Sub Sends are splitters; they split the signal – keeping the one going to the House or recorder – and allowing you to send a lot or a little of that signal to the Send of your choice using the Send knob. As in the Monitor amps and House amps, the volume knob will ultimately be used to send the proper signal level to the external (and internal) devices or effects.  If you ‘send’ this to a digital delay, it may also have its own input and out put level knobs.

You may also have a two-track input and/or out put.  This is for playing stereo audio devices and for a straight stereo record out option.  Handy to listen to practice tapes, intermission music, PA system tests and other performance related media.

The sound board or audio mixer represents the hub in most audio mixing and mastering functions.  everything connects to the board.  Even the lighting system will use channels in the snake to connect from stage to console.  Things get plugged into and things get plugged out of the mixer as needed.  Today’s mixers are blue tooth USB WiFi fire-wired and light-piped together and will connect to an amazing array of devices.  So far we have focused on what gets plugged to the Inputs of the sound board.  There are a number of connection possibilities for the Outputs as well. We have already discussed some of them earlier, so this can be brief as you already know a lot of this in general.

On most sound boards you have a number of analog-out options.  In earlier discussions we talked about XLR and 1/4″ cables and connectors.  These will continue to be the main ones used for outputs.  On the front or face of most mixing boards you will see a stereo headphone out.  It will usually have its own volume knob and probably a selector to pick the options to Monitor including Stereo Out, Solo, Effects Sends, Effects Returns, Sub or Groups, Auxiliary Returns, and other options.  On the back or the top of the mixing board you will see the panel for Out-put connections in different sections.  There are some rules to determine what type of Audio Cable is used and whether it is a male end or female end and whether it has two connectors or three (or more).

In the early days of mixing boards, microphones and keyboards, it was important which brand you purchased.  If you wanted to get ‘that sound’ you had to have this mixing board channel strip or that particular keyboard.  Later on the computer industry similarly shot through their early days and you had the Macintosh or the Windows PC.  If you were brought up with one you could not be talked into the other.  Most modern equipment from PC’s to Automobiles can do everything.  They all have similar platforms and emulators.  There is style and quality as there always will be, but you can get software mixing programs and microphone/guitar emulator plugins that will make your audio tracks sound like anything you want —-THEY CAN EVEN MAKE YOU SOUND LIKE YOU ARE SINGING IN TUNE!!

So if you like Pepsi, no problem.  Want Coke?  Press this button……  More comfortable using a Mac?  Go for it.

All it takes is cash, a thorough understanding of what all the terms mean and a good idea where all the buttons are?!!?

Enjoy!

I am famous for doing things the easy way and if I can, as cheap as possible.  Now that does not mean forget quality and versatility.  It means I won’t spend money on gadgets that I don’t need.  I try to run as clean a mix as possible, and making sure everyone gets heard.  If they are up there ‘playin it‘, I want the audience to hear it.  In reality, it doesn’t take a lot of gadgets to accomplish those two major things; make it sound good and loud enough for the venue, and put all instruments/vocals/strings/spoons or tambourines, I don’t care what it is….  in the mix.   As a band member, hiring sound guys and their rigs, a number of times after sound check and a few songs of the first set, my microphone was turned down so low, no one could hear me even in-between songs.  I could not get the sound man’s attention, or anyone else’s for that matter because no one could hear me (and as a keyboard player I was usually in the back corner of the stage in the shadows Ha!).  So eventually I just adjusted the microphone stand down toward the floor in front of me.  It is easy to hit the wrong button or turn the wrong knob; happens all the time.

Remember that the sound guy cannot hear what is really happening up on stage.  Sometimes you THINK you can.  But you as the sound engineer should be the first person to know what is going wrong when it does.  Keep an eye on all performers – they will look to you first.  As a performer and studio guy, I could tell when the guitar player broke a string, or if the drum head split and when or if the drummer had too much to drink on his birthday gig.  Things will go wrong but a lot of the time it is the sound guy.  You make an adjustment and grab the wrong knob.  They all look alike in the dark part of the venue or room.  The consequences can be anything from a non-event to a full blown crisis, depending on which knob you grab.  Obviously for the extreme crisis, you will know right away what happened and will probably be able to correct quickly.

It is the slow creepy ones that will get you.  Two songs later something changes on stage and chaos begins.

I suggested we set up the mixing board so the FX Returns are plugged into open channels so you can control their volume with the faders rather than the FX Return knobs.  I always turn the effects down in-between songs.  (you also get EQ and other benefits)  This makes it SOOO much easier to see in the dark clubs. I also use the sub-groups to assign drums, vocals, and other groups of mics their own fader that feeds directly to the Main Out or house out.  If there is a problem with one group, you can quickly test by adjusting that sub-group fader and see if problem goes away.  If not, return it to where it was and go to the next sub-group.  This way you do not have to go through fader after fader searching for a bad signal or feedback loop.   Once you narrow down the offending group, you will have a much better idea what the source is!

I would say most live performances the sound board is mixed to a Mono output.  In smaller rooms or clubs, I loved running in stereo.  I mixed for keyboard progressive bands a lot and the stereo keyboards and samplers consumed the rooms when mixed right.  Not in volume——– The vocals (sometimes three sometimes five in the band) panned as well.  Overkill in a way, but not much work and easy to arrange with equipment versatility.  Most boards have stereo FX that can add lot to the imaging.  But again, that is not the norm.  So you can either set board up in stereo and have the Main Output plugged into the MONO OUT to your system, or you can mix to mono and use one Main fader or the other.  That’s about it.  We have covered the entire mixing board, in its basic format.  Headphone outs, Tape or other inputs, on-board effects, Solo or Audition functions as well as digital features make new sections.
